826947-6
Manufacturer:
TE Connectivity
Mfr.Part #:
826947-6
Datasheet:
Description:
Headers and Wire Housings Through Hole Header, Pin, Plug Number of Positions:6 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Length | 15.24 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -65 °C |
| Height | 3.45 mm |
| Packaging | Box |
| Depth | 10.8 mm |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| Insulation Resistance | 5 GΩ |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Lead Length | 3.19786 mm |
| Contact Material(Contact Finish) | Brass |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Flammability Rating | UL94 V-0 |
| Orientation | Right Angle |
| Lifecycle Status | Production (Last Updated: 1 week ago) |
| Color | Green |
| Gender | Male Pin |
| Number of Contacts | 6 |
| Number of Poles | 6 |
| Connector Type | Header, Pin, Plug |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Row Spacing | 2.54 mm |
| Housing Material | PBT |
| Contact Style | Pin |
| Contact Current Rating | 5 A |
| Housing Color | Green |
| Keyed | No |
| PCB Mounting Orientation | Right Angle |
| Plating Thickness | 2 µm |
| Contact Gender | Male |
| High Temperature Housing | No |
| Mating Post Length | 6.7 mm |
| Contact Shape | Square |
| High Speed Serial Data Connector | No |
| Termination Post Length | 3.2 mm |
Stock: 4167
Distributors
pcbx
pcbxUnit Price$0.20006
Ext.Price$0.20006
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.20006 | $0.20006 |
| 10 | $0.19919 | $1.99190 |
| 25 | $0.19833 | $4.95825 |
| 50 | $0.19747 | $9.87350 |
| 100 | $0.19661 | $19.66100 |
| 300 | $0.19576 | $58.72800 |
| 500 | $0.19491 | $97.45500 |
| 1000 | $0.19407 | $194.07000 |
| 3000 | $0.18029 | $540.87000 |
| 5000 | $0.16749 | $837.45000 |
| 10000 | $0.15560 | $1556.00000 |
